Adding custom documentation

Added in eventcatalog@2.33.0

Getting started

Custom documentation requires a Starter or Scale plan, you can get a 14 day free trial to test it out at EventCatalog Cloud. Once you have a license key you can start to use the feature.

Adding custom documentation

Custom documentation is split into two parts:

1. Creating your documentation (markdown files)
2. Configuring your sidebar (eventcatalog.config.js)

Creating documentation

Custom documentation is stored in the /docs folder in your catalog (see example on GitHub), and can be accessed via the url /docs/custom/.

All documentation is a .mdx (markdown ) file. You can organize these however you want, for example:

docs/
├── architecture-decision-records/
│   ├── drafts/
│   │   ├── 01-introduction.mdx
│   │   ├── 02-example-record.mdx
│   ├── published/
│   │   ├── 01-introduction.mdx
│   │   ├── 02-example-record.mdx
│   ├── examples/
│   │   ├── 01-introduction.mdx
│   │   ├── 02-example-record.mdx
├── runbooks/
│   ├── 01-introduction.mdx
│   ├── 02-deployment-procedure.mdx
│   ├── 03-disaster-recovery.mdx
│   ├── 04-incident-response.mdx

In this example we have a custom documentation for:

• architecture Decision Records
• Runbooks

Organize your documentation

We added numbers (01, 02, 03) to the files to help with maintenance, you can configure the order of the files in your configuration.

Structure of markdown files

Each markdown file is split into two parts:

1. The frontmatter (properties at the top of the file)
2. The content (the rest of the file)

---
title: Creating new microservices
summary: A comprehensive guide to creating new microservices at FlowMart following our best practices and standards
owners:
  - dboyne
badges:
  - content: 'Guide'
    backgroundColor: 'teal'
    textColor: 'teal'
---

This is your content for your file.

Frontmatter properties

Property	Required	Description
title	Yes	The title of the page
summary	Yes	A summary of the page
slug	No	Ability to override the slug (url) of the page
owners	No	Owners of the page (EventCatalog owners)
badges	No	The badges of the page

Sidebar configuration

You need to configure the sidebar to include your custom documentation, we do this by using the customDocs property in your eventcatalog.config.js file.

We have two options for the sidebar:

1. Manually map files and paths to the sidebar
2. Use the autogenerated option to generate the sidebar items

Autogenerated sidebar

The autogenerated sidebar is the easiest option, it will render all the files in the directory and subdirectories. If you want to choose which files and order they are displayed in, you can manually map the files and paths to the sidebar.

export default {
  // rest of your config
  customDocs: {
    sidebar: [
      {
        label: 'architecture Decision Records',
        badge: {
          text: 'New', color: 'green'
        },
        collapsed: false,
        items: [
          {
            // Here we map the directory, and use autogenerated to generate the sidebar items
            // Any item added to the folder will be rendered automatically in EventCatalog
            label: 'Drafts', autogenerated: { directory: '/architecture-decision-records/drafts' }
          },
          {
            label: 'Published', autogenerated: { directory: '/architecture-decision-records/published' }
          },
          {
            label: 'Examples', autogenerated: { directory: '/architecture-decision-records/examples' }
          }
        ]
      },
      {
        label: 'Runbooks',
        badge: {
          text: 'New', color: 'green'
        },
        collapsed: false,
        items: [
          {
            // Here we create custom pages in the sidebar
            // We can manually map the slug to a file, or use the autogenerated to generate the sidebar items
            label: 'Creating a new runbook', items: [
              { label: 'Introduction', slug: 'runbooks/01-introduction' },
              { label: 'Deployment Procedure', slug: 'runbooks/02-deployment-procedure' },
              { label: 'Disaster Recovery', slug: 'runbooks/03-disaster-recovery' },
              { label: 'Incident Response', slug: 'runbooks/04-incident-response' },
            ]
          },
        ]
      }
    ]
  }
};

Rendered output

The rendered output will be the content of the markdown file, with the frontmatter properties.

View demo
